5580-5585 "Running line" with removable center disc

About the product

Load cell specifically designed to measure tensile forces in runs of cable or rope. The removable center disc allows easy installation without cutting the cable or rope. Up to Ø115 and 600 tons.

Key features

• Wide range of cables (Ø from 6 up to 115 mm)
• Protection: IP67
• Material:
• load pin: stainless steel
• Other elements: stainless steel (5580)
• Other elements : nickel plated steel (5585)
• Complete range of electronics and load limitation devices
• Custom-made manufacturing
• Available options (non-exhaustive list) :
• amplified output (V or mA)
• protection IP68 or special for marine environment
• sheaves of synthetic material

The SENSY's load cells 5580 and 5585 are perfectly designed for the following applications

Tension measurement of towage and haulage cable - Force measurement of winches - Load limitation of hoisting devices, cranes and overhead cranes (in combination with load limitation devices (CRANEBOY, BRIDGEBOY, …)

CAPACITIES
5580-5585 : from 1 to 40 t (up to 600t on request)
