Temperature sensor TGL00941 CLTS
About the product
Designed for temperature measurement in cylinder walls and similar applications.
The TGL00941 temperature sensor is an invasive PT100 with 3mm probe tube
Cylinder Liner Temperature Sensor Series TGL00921-4 (invasive measurement) are very fast responding temperature sensors (PT100 3-wire) with diameter 3mm at the measuring tip. They are inserted and screwed into the application. Output via I²C bus.
Technical data sensor tip/connection box:
Dimensions: Diameter tip 3mm x length variable 120..180mm
Output signal: I²C
Temperature range: -20...+180°C
Connected to junction box (also 2 sensors) 125 x 80 x 57mm
Housing: stainless steel
Typical applications
-
Energy
-
Machine & Propulsion
Manufacturer
About the product
Designed for temperature measurement in cylinder walls and similar applications.
The TGL00941 temperature sensor is an invasive PT100 with 3mm probe tube
Cylinder Liner Temperature Sensor Series TGL00921-4 (invasive measurement) are very fast responding temperature sensors (PT100 3-wire) with diameter 3mm at the measuring tip. They are inserted and screwed into the application. Output via I²C bus.
Technical data sensor tip/connection box:
Dimensions: Diameter tip 3mm x length variable 120..180mm
Output signal: I²C
Temperature range: -20...+180°C
Connected to junction box (also 2 sensors) 125 x 80 x 57mm
Housing: stainless steel
